MOD-P1352DR

> How to identify

MODS100
Foundation downlight
M-PROOF［IP65 moisture proof］

Aperture for installation：φ100
Ra93typ
Color temperature：2400/2700/3000/3500/4000
Cone： WC/BF/NC
* Please check the specification sheet regarding the driver matches to the lighting fixture.

  • MOD-P1352DR white
  • MOD-P1352DR white
  • MOD-P1352DR matte black
  • MOD-P1352DR white
  • MOD-P1352DR matte black

Products Specifications

Input Voltage *reference data
Driverless:19.5V
0-10V:220/242V
Power consumption *reference data
16.8W（220V）
17.0W（240V）
Luminance flux *reference data
1156～1432lm
Color rendering
(Typical data)
Ra93typ
Color temperature
2400～
4000K
Light distrobution
M.N.SP.W
Input current *reference data
Driverless:0.7A
0-10V:0.089A
0.087A
Fixture's weight
Driverless;460g
0-10V:710g
Aiming distance
0.1m
Tilting angle
-
Glare cut off
angle
30°
Filter lighting®
-
Ceiling thickness
9～25mm
Dimming
-

Data Download

Specification Sheet/ Installation Guide/ Product Specification Sheet Fixture Drawing/CAD Data IES Data
MOD-P1352DR Specification Sheet MOD-P1352DR CAD Data MOD-P1352DR IES Data
Specification Sheet
PDF Installation Guide
PDF Product specification sheet
JPG
DXF 		BF_Medium
ies BF_Narrow
ies BF_Spread
ies BF_Wide
ies NC_Medium
ies NC_Narrow
ies NC_Spread
ies NC_Wide
ies WC_Medium
ies WC_Narrow
ies WC_Spread
ies WC_Wide
ies
Driverless
Light DistributionCorn ColorFlame Color 2400K 2700K 3000K 3500K 4000K
M white white MOD-P1352DR/CE/M/R24B/WC/White
-		 MOD-P1352DR/CE/M/R27B/WC/White
-		 MOD-P1352DR/CE/M/R30B/WC/White
-		 MOD-P1352DR/CE/M/R35B/WC/White
-		 MOD-P1352DR/CE/M/R40B/WC/White
-
natural white MOD-P1352DR/CE/M/R24B/NC/White
-		 MOD-P1352DR/CE/M/R27B/NC/White
-		 MOD-P1352DR/CE/M/R30B/NC/White
-		 MOD-P1352DR/CE/M/R35B/NC/White
-		 MOD-P1352DR/CE/M/R40B/NC/White
-
matte black MOD-P1352DR/CE/M/R24B/NC/Matte black
-		 MOD-P1352DR/CE/M/R27B/NC/Matte black
-		 MOD-P1352DR/CE/M/R30B/NC/Matte black
-		 MOD-P1352DR/CE/M/R35B/NC/Matte black
-		 MOD-P1352DR/CE/M/R40B/NC/Matte black
-
black baffle white MOD-P1352DR/CE/M/R24B/BF/White
-		 MOD-P1352DR/CE/M/R27B/BF/White
-		 MOD-P1352DR/CE/M/R30B/BF/White
-		 MOD-P1352DR/CE/M/R35B/BF/White
-		 MOD-P1352DR/CE/M/R40B/BF/White
-
matte black MOD-P1352DR/CE/M/R24B/BF/Matte black
-		 MOD-P1352DR/CE/M/R27B/BF/Matte black
-		 MOD-P1352DR/CE/M/R30B/BF/Matte black
-		 MOD-P1352DR/CE/M/R35B/BF/Matte black
-		 MOD-P1352DR/CE/M/R40B/BF/Matte black
-
N white white MOD-P1352DR/CE/N/R24B/WC/White
-		 MOD-P1352DR/CE/N/R27B/WC/White
-		 MOD-P1352DR/CE/N/R30B/WC/White
-		 MOD-P1352DR/CE/N/R35B/WC/White
-		 MOD-P1352DR/CE/N/R40B/WC/White
-
natural white MOD-P1352DR/CE/N/R24B/NC/White
-		 MOD-P1352DR/CE/N/R27B/NC/White
-		 MOD-P1352DR/CE/N/R30B/NC/White
-		 MOD-P1352DR/CE/N/R35B/NC/White
-		 MOD-P1352DR/CE/N/R40B/NC/White
-
matte black MOD-P1352DR/CE/N/R24B/NC/Matte black
-		 MOD-P1352DR/CE/N/R27B/NC/Matte black
-		 MOD-P1352DR/CE/N/R30B/NC/Matte black
-		 MOD-P1352DR/CE/N/R35B/NC/Matte black
-		 MOD-P1352DR/CE/N/R40B/NC/Matte black
-
black baffle white MOD-P1352DR/CE/N/R24B/BF/White
-		 MOD-P1352DR/CE/N/R27B/BF/White
-		 MOD-P1352DR/CE/N/R30B/BF/White
-		 MOD-P1352DR/CE/N/R35B/BF/White
-		 MOD-P1352DR/CE/N/R40B/BF/White
-
matte black MOD-P1352DR/CE/N/R24B/BF/Matte black
-		 MOD-P1352DR/CE/N/R27B/BF/Matte black
-		 MOD-P1352DR/CE/N/R30B/BF/Matte black
-		 MOD-P1352DR/CE/N/R35B/BF/Matte black
-		 MOD-P1352DR/CE/N/R40B/BF/Matte black
-
SP white white MOD-P1352DR/CE/SP/R24B/WC/White
-		 MOD-P1352DR/CE/SP/R27B/WC/White
-		 MOD-P1352DR/CE/SP/R30B/WC/White
-		 MOD-P1352DR/CE/SP/R35B/WC/White
-		 MOD-P1352DR/CE/SP/R40B/WC/White
-
natural white MOD-P1352DR/CE/SP/R24B/NC/White
-		 MOD-P1352DR/CE/SP/R27B/NC/White
-		 MOD-P1352DR/CE/SP/R30B/NC/White
-		 MOD-P1352DR/CE/SP/R35B/NC/White
-		 MOD-P1352DR/CE/SP/R40B/NC/White
-
matte black MOD-P1352DR/CE/SP/R24B/NC/Matte black
-		 MOD-P1352DR/CE/SP/R27B/NC/Matte black
-		 MOD-P1352DR/CE/SP/R30B/NC/Matte black
-		 MOD-P1352DR/CE/SP/R35B/NC/Matte black
-		 MOD-P1352DR/CE/SP/R40B/NC/Matte black
-
black baffle white MOD-P1352DR/CE/SP/R24B/BF/White
-		 MOD-P1352DR/CE/SP/R27B/BF/White
-		 MOD-P1352DR/CE/SP/R30B/BF/White
-		 MOD-P1352DR/CE/SP/R35B/BF/White
-		 MOD-P1352DR/CE/SP/R40B/BF/White
-
matte black MOD-P1352DR/CE/SP/R24B/BF/Matte black
-		 MOD-P1352DR/CE/SP/R27B/BF/Matte black
-		 MOD-P1352DR/CE/SP/R30B/BF/Matte black
-		 MOD-P1352DR/CE/SP/R35B/BF/Matte black
-		 MOD-P1352DR/CE/SP/R40B/BF/Matte black
-
W white white MOD-P1352DR/CE/W/R24B/WC/White
-		 MOD-P1352DR/CE/W/R27B/WC/White
-		 MOD-P1352DR/CE/W/R30B/WC/White
-		 MOD-P1352DR/CE/W/R35B/WC/White
-		 MOD-P1352DR/CE/W/R40B/WC/White
-
natural white MOD-P1352DR/CE/W/R24B/NC/White
-		 MOD-P1352DR/CE/W/R27B/NC/White
-		 MOD-P1352DR/CE/W/R30B/NC/White
-		 MOD-P1352DR/CE/W/R35B/NC/White
-		 MOD-P1352DR/CE/W/R40B/NC/White
-
matte black MOD-P1352DR/CE/W/R24B/NC/Matte black
-		 MOD-P1352DR/CE/W/R27B/NC/Matte black
-		 MOD-P1352DR/CE/W/R30B/NC/Matte black
-		 MOD-P1352DR/CE/W/R35B/NC/Matte black
-		 MOD-P1352DR/CE/W/R40B/NC/Matte black
-
black baffle white MOD-P1352DR/CE/W/R24B/BF/White
-		 MOD-P1352DR/CE/W/R27B/BF/White
-		 MOD-P1352DR/CE/W/R30B/BF/White
-		 MOD-P1352DR/CE/W/R35B/BF/White
-		 MOD-P1352DR/CE/W/R40B/BF/White
-
matte black MOD-P1352DR/CE/W/R24B/BF/Matte black
-		 MOD-P1352DR/CE/W/R27B/BF/Matte black
-		 MOD-P1352DR/CE/W/R30B/BF/Matte black
-		 MOD-P1352DR/CE/W/R35B/BF/Matte black
-		 MOD-P1352DR/CE/W/R40B/BF/Matte black
-
0-10V
Light DistributionCorn ColorFlame Color 2400K 2700K 3000K 3500K 4000K
M white white MOD-P1352DR/Z102/M/R24B/WC/White
-		 MOD-P1352DR/Z102/M/R27B/WC/White
-		 MOD-P1352DR/Z102/M/R30B/WC/White
-		 MOD-P1352DR/Z102/M/R35B/WC/White
-		 MOD-P1352DR/Z102/M/R40B/WC/White
-
natural white MOD-P1352DR/Z102/M/R24B/NC/White
-		 MOD-P1352DR/CZ102/M/R27B/NC/White
-		 MOD-P1352DR/Z102/M/R30B/NC/White
-		 MOD-P1352DR/Z102/M/R35B/NC/White
-		 MOD-P1352DR/Z102/M/R40B/NC/White
-
matte black MOD-P1352DR/Z102/M/R24B/NC/Matte black
-		 MOD-P1352DR/Z102/M/R27B/NC/Matte black
-		 MOD-P1352DR/Z102/M/R30B/NC/Matte black
-		 MOD-P1352DR/Z102/M/R35B/NC/Matte black
-		 MOD-P1352DR/Z102/M/R40B/NC/Matte black
-
black baffle white MOD-P1352DR/Z102/M/R24B/BF/White
-		 MOD-P1352DR/Z102/M/R27B/BF/White
-		 MOD-P1352DR/Z102/M/R30B/BF/White
-		 MOD-P1352DR/Z102/M/R35B/BF/White
-		 MOD-P1352DR/Z102/M/R40B/BF/White
-
matte black MOD-P1352DR/Z102/M/R24B/BF/Matte black
-		 MOD-P1352DR/Z102/M/R27B/BF/Matte black
-		 MOD-P1352DR/Z102/M/R30B/BF/Matte black
-		 MOD-P1352DR/Z102/M/R35B/BF/Matte black
-		 MOD-P1352DR/Z102/M/R40B/BF/Matte black
-
N white white MOD-P1352DR/Z102/N/R24B/WC/White
-		 MOD-P1352DR/Z102/N/R27B/WC/White
-		 MOD-P1352DR/Z102/N/R30B/WC/White
-		 MOD-P1352DR/Z102/N/R35B/WC/White
-		 MOD-P1352DR/Z102/N/R40B/WC/White
-
natural white MOD-P1352DR/Z102/N/R24B/NC/White
-		 MOD-P1352DR/Z102/N/R27B/NC/White
-		 MOD-P1352DR/Z102/N/R30B/NC/White
-		 MOD-P1352DR/Z102/N/R35B/NC/White
-		 MOD-P1352DR/Z102/N/R40B/NC/White
-
matte black MOD-P1352DR/Z102/N/R24B/NC/Matte black
-		 MOD-P1352DR/Z102/N/R27B/NC/Matte black
-		 MOD-P1352DR/Z102/N/R30B/NC/Matte black
-		 MOD-P1352DR/Z102/N/R35B/NC/Matte black
-		 MOD-P1352DR/Z102/N/R40B/NC/Matte black
-
black baffle white MOD-P1352DR/Z102/N/R24B/BF/White
-		 MOD-P1352DR/Z102/N/R27B/BF/White
-		 MOD-P1352DR/Z102/N/R30B/BF/White
-		 MOD-P1352DR/Z102/N/R35B/BF/White
-		 MOD-P1352DR/Z102/N/R40B/BF/White
-
matte black MOD-P1352DR/Z102/N/R24B/BF/Matte black
-		 MOD-P1352DR/Z102/N/R27B/BF/Matte black
-		 MOD-P1352DR/Z102/N/R30B/BF/Matte black
-		 MOD-P1352DR/Z102/N/R35B/BF/Matte black
-		 MOD-P1352DR/Z102/N/R40B/BF/Matte black
-
SP white white MOD-P1352DR/Z102/SP/R24B/WC/White
-		 MOD-P1352DR/Z102/SP/R27B/WC/White
-		 MOD-P1352DR/Z102/SP/R30B/WC/White
-		 MOD-P1352DR/Z102/SP/R35B/WC/White
-		 MOD-P1352DR/Z102/SP/R40B/WC/White
-
natural white MOD-P1352DR/Z102/SP/R24B/NC/White
-		 MOD-P1352DR/Z102/SP/R27B/NC/White
-		 MOD-P1352DR/Z102/SP/R30B/NC/White
-		 MOD-P1352DR/Z102/SP/R35B/NC/White
-		 MOD-P1352DR/Z102/SP/R40B/NC/White
-
matte black MOD-P1352DR/Z102/SP/R24B/NC/Matte black
-		 MOD-P1352DR/Z102/SP/R27B/NC/Matte black
-		 MOD-P1352DR/Z102/SP/R30B/NC/Matte black
-		 MOD-P1352DR/Z102/SP/R35B/NC/Matte black
-		 MOD-P1352DR/Z102/SP/R40B/NC/Matte black
-
black baffle white MOD-P1352DR/Z102/SP/R24B/BF/White
-		 MOD-P1352DR/Z102/SP/R27B/BF/White
-		 MOD-P1352DR/Z102/SP/R30B/BF/White
-		 MOD-P1352DR/Z102/SP/R35B/BF/White
-		 MOD-P1352DR/Z102/SP/R40B/BF/White
-
matte black MOD-P1352DR/Z102/SP/R24B/BF/Matte black
-		 MOD-P1352DR/Z102/SP/R27B/BF/Matte black
-		 MOD-P1352DR/Z102/SP/R30B/BF/Matte black
-		 MOD-P1352DR/Z102/SP/R35B/BF/Matte black
-		 MOD-P1352DR/Z102/SP/R40B/BF/Matte black
-
W white white MOD-P1352DR/Z102/W/R24B/WC/White
-		 MOD-P1352DR/Z102/W/R27B/WC/White
-		 MOD-P1352DR/Z102/W/R30B/WC/White
-		 MOD-P1352DR/Z102/W/R35B/WC/White
-		 MOD-P1352DR/Z102/W/R40B/WC/White
-
natural white MOD-P1352DR/Z102/W/R24B/NC/White
-		 MOD-P1352DR/Z102/W/R27B/NC/White
-		 MOD-P1352DR/Z102/W/R30B/NC/White
-		 MOD-P1352DR/Z102/W/R35B/NC/White
-		 MOD-P1352DR/Z102/W/R40B/NC/White
-
matte black MOD-P1352DR/Z102/W/R24B/NC/Matte black
-		 MOD-P1352DR/Z102/W/R27B/NC/Matte black
-		 MOD-P1352DR/Z102/W/R30B/NC/Matte black
-		 MOD-P1352DR/Z102/W/R35B/NC/Matte black
-		 MOD-P1352DR/Z102/W/R40B/NC/Matte black
-
black baffle white MOD-P1352DR/Z102/W/R24B/BF/White
-		 MOD-P1352DR/Z102/W/R27B/BF/White
-		 MOD-P1352DR/Z102/W/R30B/BF/White
-		 MOD-P1352DR/CZ102/W/R35B/BF/White
-		 MOD-P1352DR/Z102/W/R40B/BF/White
-
matte black MOD-P1352DR/Z102/W/R24B/BF/Matte black
-		 MOD-P1352DR/Z102/W/R27B/BF/Matte black
-		 MOD-P1352DR/Z102/W/R30B/BF/Matte black
-		 MOD-P1352DR/Z102/W/R35B/BF/Matte black
-		 MOD-P1352DR/Z102/W/R40B/BF/Matte black
-
